代 號

螺紋 THREAD

管子直徑

尺 寸 DIMENSIONS

PART NO.

E

TUBE O.D.

A

B

D

L

S

1BW-04-10

G1/4"X19

10

12

7

10

25

19

1BW-06-14

G3/8"X19

14

13.5

8

14

29.5

22

1BW-08-18

G1/2"X14

18

16

10

18

36

27

1BW-12-22

G3/4"X14

22

18.5

10

22

39.5

32

1BW-12-28

G3/4"X14

28

18.5

12

28

41.5

32

1BW-16-28

G1"X11

28

20.5

12

28

45.5

41

1BW-16-30

G1"X11

30

20.5

12

30

45.5

41

1BW-20-34

G1.1/4"X11

34

20.5

14

34

49.5

50

1BW-20-36

G1.1/4"X11

36

20.5

14

36

49.5

50

1BW-20-42

G1.1/4"X11

42

20.5

16

42

51.5

50

1BW-24-36

G1.1/2"X11

36

23

14

36

52

55

1BW-24-42

G1.1/2"X11

42

23

16

42

54

55

1BW-24-50

G1.1/2"X11

50

23

16

50

54

55
